TSG R0005-2011 "Safety Technical Supervision Regulation for Mobile Pressure Vessels"Q/1500LXZ004-2019 "Compressed Gas Long-tube Trailers"Q/1500LXZ002-2019 "Compressed Gas Tube Skids"
Product Series
Nominal working pressure: 20 MPa Available in φ559 and φ715 series
φ559 Series Specifications
9 or 10 tubes Water volume: 21.42 m³ (9-tube) / 22.5 m³ (10-tube)
φ715 Series Specifications
6 or 7 tubes Water volumes: 23.58 m³, 25.02 m³, 26.67 m³ (depending on tube count)
Charging Mediums
CNG, H₂, He and other gases
Export Transport & Delivery
Available for export; shipping terms to be agreed
Minimum Order Quantity (MOQ)
1 piece
Payment Terms
To be negotiated (e.g., T/T, L/C, etc.)
Specification
Dimensions (Length × Width × Height) (mm)
Nominal working capacity (MPa)
Water volume (m3)
Inflation volume (Kg)
Certifiable Projects
GSJ08-2180-CNG-25
12192×2438×1400
25
17.44
2747
CSC/ADR/MEGC
GSJ08-2450-CNG-25
12192×2438×1400
25
19.6
3087
CSC/ADR/MEGC
GSJ08-2210-CNG-25
12192×2438×1400
25
17.68
3978
CSC/ADR/MEGC
GSJ09-2320-CNG-25
12192×2438×1890
25
20.88
4660
CSC/ADR/MEGC
GSJ09-2450-CNG-25
12192×2438×1890
25
22.05
4960
CSC/ADR/MEGC
GSJ10-2320-CNG-25
12192×2438×1890
25
23.2
5220
CSC/ADR/MEGC
GSJ10-2450-CNG-25
12192×2438×1890
25
24.5
5512
CSC/ADR/MEGC
GSJ11-2320-CNG-25
12192×2438×1890
25
25.52
5742
CSC/ADR/MEGC
GSJ11-2450-CNG-25
12192×2438×1890
25
26.95
6063
CSC/ADR/MEGC
GSJ12-2320-CNG-25
12192×2438×2000
25
27.84
6264
CSC/ADR/MEGC
GSJ12-2450-CNG-25
12192×2438×2000
25
29.4
6612
CSC/ADR/MEGC
GSJ16-2450-CNG-25
12192×2438×2595
25
39.2
8890
CSC/ADR/MEGC
factory Showcase
Certificate Display
FAQ
Q:
What is the inspection cycle for gas cylinders?
A:
According to the national "Technical Regulations for Gas Cylinder Safety," LNG cylinders for vehicles must be inspected every 3 years, and industrial gas cylinders every 5 years. Our company provides one-stop testing services and can assist with obtaining test reports and compliance registration.
Q:
What are the differences between LNG cylinders and CNG cylinders?
A:
LNG is cryogenic liquefied natural gas with higher energy density and a range of over 600 kilometers, making it suitable for long-haul heavy trucks; CNG is compressed gaseous natural gas with more widespread refueling stations, making it suitable for short-distance delivery vehicles.
Q:
What certifications are required for exporting gas cylinders?
A:
Exporting to the EU requires CE certification, exporting to North America requires DOT certification, and exporting to Southeast Asia requires PS certification. Our company can assist with the entire certification process to ensure that products meet the market access requirements of the target market.
